Crystal Lattice Structures: | Creation Date: 4 Mar 2002 |
Last Modified: 28 Jul 2008 |
You can now
A1 | = | a X |
A2 | = | b Y |
A3 | = | c cos(β) X + c sin(β) Z |
B1 | = | + x1 A1 + y1 A2 + z1 A3 | = | + [x1 a + z1 c cos(β)] X + y1 b Y + z1 c sin(β) Z | (2a) | (Ti-I) |
B2 | = | - x1 A1 + (½ + y1) A2 - z1 A3 | = | - [x1 a + z1 c cos(β)] X + (½ + y1) b Y - z1 c sin(β) Z | (2a) | (Ti-I) |
B3 | = | + x2 A1 + y2 A2 + z2 A3 | = | + [x2 a + z2 c cos(β)] X + y2 b Y + z2 c sin(β) Z | (2a) | (Ti-II) |
B4 | = | - x2 A1 + (½ + y2) A2 - z2 A3 | = | - [x2 a + z2 c cos(β)] X + (½ + y2) b Y - z2 c sin(β) Z | (2a) | (Ti-II) |
