| Crystal Lattice Structures: | Creation Date: 21 Feb 2002 |
| Last Modified: 21 Oct 2004 |
You can now
| A1 | = | a X |
| A2 | = | a Y |
| A3 | = | c Z |
| B1 | = | ½ A2 | = | ½ a Y | (Pd-I) | (2c) |
| B2 | = | ½ A1 + ½ A3 | = | ½ a X + ½ a Z | (Pd-I) | (2c) |
| B3 | = | ¼ A3 | = | ¼ a Z | (Pd-II) | (2e) |
| B4 | = | ¾ A3 | = | ¾ a Z | (Pd-II) | (2e) |
| B5 | = | + xPd A1 + yPd A2 | = | + xPd a X + yPd a Y | (Pd-III) | (4j) |
| B6 | = | - xPd A1 - yPd A2 | = | - xPd a X - yPd a Y | (Pd-III) | (4j) |
| B7 | = | - yPd A1 + xPd A2 + ½ A3 | = | - yPd a X + xPd a Y + ½ Z | (Pd-III) | (4j) |
| B8 | = | + yPd A1 - xPd A2 + ½ A3 | = | + yPd a X - xPd a Y + ½ Z | (Pd-III) | (4j) |
| B9 | = | + xS A1 + yS A2 + zS A3 | = | + xS a X + yS a Y + zS Z | (S) | (8k) |
| B10 | = | - xS A1 - yS A2 + zS A3 | = | - xS a X - yS a Y + zS Z | (S) | (8k) |
| B11 | = | - xS A1 - yS A2 - zS A3 | = | - xS a X - yS a Y - zS Z | (S) | (8k) |
| B12 | = | + xS A1 + yS A2 - zS A3 | = | + xS a X + yS a Y - zS Z | (S) | (8k) |
| B13 | = | - yS A1 + xS A2 + (½ + zS) A3 | = | - yS a X + xS a Y + (½ + zS) Z | (S) | (8k) |
| B14 | = | + yS A1 - xS A2 + (½ + zS) A3 | = | + yS a X - xS a Y + (½ + zS) Z | (S) | (8k) |
| B15 | = | + yS A1 - xS A2 + (½ - zS) A3 | = | + yS a X - xS a Y + (½ - zS) Z | (S) | (8k) |
| B16 | = | - yS A1 + xS A2 + (½ - zS) A3 | = | - yS a X + xS a Y + (½ - zS) Z | (S) | (8k) |
